12 Dc Motor 9000 Rpm Brush Micro Motor 6-24v Is Available

12V DC Motor 9000 RPM Brush Micro Motor (6-24V Range Available)

Product Description

Technical Specifications of Brush Micro Motor

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
Model		Operating Range	Nominal	Speed (RPM)	Current (A)	Speed (RPM)	Current (A)	Torque (mN.m / gf.cm)	Power (W)	Current (A)	Torque (mN.m / gf.cm)
RS-380SH	4052	3.0~6.0	4.8VDC	7800	0.32	6701	1.95	9.9 / 101	6.98	11.9	70.6 / 720
RS-380SH	3557	6.0~12.0	12VDC	21200	0.44	18367	2.85	11.26 / 114.9	21.68	18.5	84.3 / 860
RS-385SH	17110	6.0~24.0	24VDC	11000	0.15	9034	0.69	10.7 / 109	10.12	3.16	59.8 / 610
RS-385SH	2267	6.0~12.0	12VDC	10000	0.17	8340	0.85	7.5 / 76.5	6.53	4.29	45 / 459

Application

Our Company

Established in 2005, the manufacturer is a high-tech enterprise integrating the research, development, production and sales of various kinds of micro DC motor, geared motor, planetary geared motor, shade pole geared motor and special gearbox motor. Products are widely used in automobiles, communications equipment, smart home, medical equipment, intelligent security, household appliances, western kitchen equipment, machinery and electronics and other high-end transmission structures. Products are exported to more than 50 countries and regions worldwide.

Production Process

Certifications

Frequently Asked Questions

Q Are you a trading company or manufacturer?

We are a factory. We have specialized in micro DC motors and DC gear motors for more than 14 years.

Q What is the payment term for new customers?

We support secure online payment methods including credit cards (Mastercard, Visa), PayPal, and TT (Telegraphic Transfer).

Q Can you customize the motor if I cannot find a suitable model?

Yes, we can customize a suitable motor according to our customers' specific requirements, including voltage, speed, torque, and configuration.

Q Do you have certificates for your motors?

Yes, we have CE, FCC, ISO, and other relevant standard certificates. If your project has other certification requirements, we can apply for them for you.

Q How is your Quality Control managed?

We have professional checking staff on every production line process. After finishing the whole motor, we use specialized quality machinery to test the product, such as Hardness Testers, 2.5D Image Testers, Salt Spray Chambers, Life Testers, Temperature Test Machines, and Noise testers.

Q What is the available voltage range for the micro brush motor?

The motor is highly versatile and supports operating ranges starting from 3V up to 24V DC depending on the customized model parameters selected.
