SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

1 / 4

SRC-370SH-4730 Factory Hot Selling 4.5V 17500rmp 3.63A Output 11.51W

Send Inquiry

Product Description

SRC-370SH-4730 Factory Hot selling 4.5V 17500rmp 3.63A output 11.51W

SRC-370SH-4730 PMDC Motor Dimension Info

Product Description

SRC-370SH-4730 PMDC Motor Detailed Drawing

PMDC MOTOR Technical Data
Model		Rated Voltage (V)		No-Load		Rated				Stall
Model		Operating Range	Nominal	Speed (RPM)	Current (mA)	Speed (RPM)	Current (mA)	Torque (mN.m / gf.cm)	Power (W)	Current (mA)	Torque (mN.m / gf.cm)
RF-370CA	061700	6.0~24.0	24 VDC	1320	3	1000	8	0.98/10	0.1	260	4.02/41
RC-370CH	20123	3.0~6.0	6 VDC	8000	70	6878	420	2.4/24.5	1.71	2550	17/173
RC-370SH	4730	3.0~5.0	4.5 VDC	17500	550	15199	3630	7.2/73.4	11.51	24000	55/561
RC-370SH	18139	6.0~12.0	12 VDC	10000	130	8439	700	5.8/59.2	5.17	3800	37.5/382.5

Please refer to the italic parameter fields in the technical table to identify distinct model configurations.

Application

Frequently Asked Questions

Q: What is the operating voltage range for the RC-370SH-4730 motor?

A: The RC-370SH-4730 PMDC motor operates within a voltage range of 3.0V to 5.0V DC, with a nominal rated operating voltage of 4.5V DC.

Q: What performance output does the RC-370SH-4730 motor deliver?

A: Under nominal 4.5V conditions, the RC-370SH-4730 features a rated speed of 15,199 RPM, draws a rated current of 3,630 mA, and outputs a rated power of 11.51W.

Q: Which applications are these PMDC micro motors suited for?

A: These motors are highly versatile and typically utilized in security systems, smart home controllers, precise electronic tools, children's electric toys, and automated equipment requiring compact high-speed drives.

Q: How does the RC-370SH-18139 model compare in rated voltage and speed?

A: The RC-370SH-18139 runs on a nominal voltage of 12V DC (operating range 6.0~12.0V) and yields a rated speed of 8,439 RPM with an output power of 5.17W.

Q: What are the stall parameters for the high-voltage RF-370CA model?

A: At a nominal 24V DC, the RF-370CA model has a stall current draw of 260 mA and produces a stall torque of 4.02 mN.m (equivalent to 41 gf.cm).

Q: Do these motors support speed customizability?

A: Yes. The technical parameters show distinct winding designs (e.g. 4730, 18139, 20123) optimized to produce varying speed and torque profiles according to design requirements.
